Being a prominent Hastelloy Coils manufacturer in Bangkok, Chanathip Nickel Alloys & Plates distributes hot and cold-rolled coils of C22, C276, and other nickel-based alloys. Our coils are manufactured to meet ASTM B575 and international standards, guaranteeing high surface quality and uniform mechanical performance. Our Hastelloy coils are offered in different widths, thicknesses, and edge finishes for use in fabrication, lining, and cladding pressure equipment and piping systems operating under corrosive conditions.
|
Standard |
ASTM B575 / ASME SB575 |
|
Thickness |
0.2mm – 5.0mm |
|
Width |
3.2mm – 1500mm |
|
Length |
AS PER CUSTOMER’S REQUIREMENT |
|
Test Certificate |
Yes |
|
Coils Hardness |
Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
|
Value Added Services |
Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
|
Form |
Coil / Strip |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.8 gm/cm3 | 0.318 lb/in3 |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Coils in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Hastelloy coils are employed in pressure vessel cladding, duct systems, marine exhausts, linings for heat exchangers, and chemical process equipment. Because of their high formability and resistance to corrosion, they are best suited for application in pollution control, flue gas desulfurization, and chemical transport systems. Offshore oil & gas, pharmaceuticals, and nuclear energy industries rely on these coils to provide structural integrity in harsh environments.
