Chanathip Nickel Alloys and Plates, a reputable manufacturer and supplier located in Bangkok, Thailand, is well-known for delivering top-notch Incoloy 825 Bars to clients in Dubai, UAE. These bars are specifically engineered to endure highly corrosive and demanding environments, making them a vital material for industries that require exceptional resistance and durability. Crafted using advanced techniques and rigorous quality controls, Incoloy 825 Bars guarantee outstanding reliability in industrial applications. The company’s dedication to providing products that meet global standards has helped it build a solid reputation in international markets.
Incoloy 825 Bars are mainly made up of nickel, iron, and chromium, with notable additions of molybdenum, copper, and titanium. This distinctive composition offers remarkable resistance to both reducing and oxidizing agents, stress corrosion cracking, and pitting. On the mechanical side, these bars showcase high tensile strength, toughness, and hardness, along with stability at elevated temperatures. Their impressive combination of mechanical properties and corrosion resistance makes them perfect for long-term use in aggressive and harsh operating conditions.
| Standard | ASTM B425, ASME SB425 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | C | Mn | Si | Al | S | Cr | Cu | Ni | Fe | Ti |
| Incoloy 825 | 0.05 max | 1.00 max | 0.05 max | 0.02 max | 0.03 max | 19.50-23.50 | 1.50-3.00 | 38.0-46.0 | 22.0 min | 0.06 – 1.20 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Bars in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Bars find extensive applications in the chemical processing, oil and gas, marine, and pollution control industries due to their exceptional corrosion resistance. They are well-suited for handling sulfuric acid, phosphoric acid, and seawater, ensuring reliable performance even in tough environments. In the oil and gas sector, these bars are commonly used in piping systems, heat exchangers, and offshore applications. Their durability also makes them a favored choice in nuclear fuel reprocessing, pollution control equipment, and marine engineering. These bars provide both structural integrity and a long service life in critical applications.
