Chanathip Nickel Alloys & Plates in Bangkok is a reliable manufacturer of nickel-based coated welding electrodes. Our ENi‑CL class electrodes are made with high-quality nickel and special coatings that provide excellent performance in challenging environments. We maintain strict metallurgical controls, high purity raw materials, controlled coating formulations, and optimized drying processes. Our ENi‑CL electrodes are supplied to industries that need high resistance to heat, corrosion, and oxidation. With both local and international customers, we provide complete documentation, testing, and support from our Bangkok facilities, ensuring electrodes perform to AWS standards under various welding conditions.
ENi‑CL electrodes are primarily nickel alloys with at least 60‑65 % nickel, along with chromium, molybdenum, and sometimes cobalt based on sub-variants. The “CL” means “corrosion-lined” or “clad lining” applications; the carbon level is low (< 0.05 %), and iron content is modest (~5‑10 %), with trace elements (Si, Mn, P, S) tightly controlled. The coating composition includes flux materials, binders, and stabilizers to aid arc stability and slag control. Mechanical properties show that deposited weld metal has a tensile strength of around 550‑700 MPa, elongation of about 30‑40 %, good impact resistance, and excellent corrosion resistance in both oxidizing and reducing environments.
| lassification | AWS A5.11, A5.1, ENi-Cl |
| Form | Welding Electrode, Welding Rods |
| Type Of Current | Direct Current Electrode Positive (DCEP) |
| Diameters | 3/32”, 1/8”, 5/32”, 3/16” or 2.5mm, Ø 3.2mm, Ø 4.0mm, Ø 5.0mm |
| Size | 2.0mm ∞ 5.0mm |
| AC/DC+ | 50-80, 80-110, 100-135, 140-180 |
| Welding Positions | All positions 5/32” & 3/16” recommended for use in flat & horizontal positions only (F, V, OH, H) |
| AWS ENi-Cl Coated Electrodes Application & uses |
|
| C | Mn | Si | S | Fe | Ni+ incidental Cobalt | Cu + incidental Silver | AL | Other |
| 2.0 | 2.5 | 4.0 | 0.03 | 8.0 | 85 min | 2.5 | 1.0 | 1.0 |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ENi-Cl Coated Electrodes in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
ENi‑CL coated electrodes are used for welding overlays, claddings, and repairs where corrosion resistance is critical, such as in chemical process equipment, storage tanks, piping, and reactors in corrosive media. They are suitable for repairing damaged surfaces in marine environments and restoring worn components exposed to acid or salt corrosion. They are also used in furnaces, boilers, and heat exchangers, especially where replacements are costly and overlay welding is a better option. In industrial maintenance, industries like petrochemical, sugar, pulp and paper, and wastewater treatment frequently use ENi‑CL electrodes to extend the service life of infrastructure facing aggressive chemicals.
