Chanathip Nickel Alloys & Plates in Bangkok manufactures pure nickel class ERNi-1 MIG/TIG filler wires and rods, developed for joining commercially pure nickel materials and similar alloys. Our products comply with AWS A5.14 / ASME SFA-5.14 standards, using high purity nickel and stabilizing additions. They are available in various diameters and lengths, featuring excellent surface finish, packaging, and traceability. These items are used in applications requiring high corrosion resistance in neutral or alkaline settings, caustic exposure, and for welding nickel 200/201. We serve industries such as chemical, marine, food processing, and specialty manufacturing both locally and internationally.
ERNi-1 weld metal is high in nickel content, typically over 93% Ni, with titanium added (around 2-3.5%) to control porosity, small amounts of iron (up to 1%), manganese (up to 1%), silicon, aluminum, and trace carbon (up to 0.15%). It has a tensile strength between 380-460 MPa, elongation around 25-30%, good ductility, and excellent corrosion resistance in alkalis, along with high thermal and electrical conductivity. The welds are clean and sound, with minimal impurities and perform well in dissimilar material joints.
| Classification | AWS A5.14, ERNi-1 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNi-1 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Si | S | P | Ni | Fe | Cu | Al | Ti |
|---|---|---|---|---|---|---|---|---|---|
| ≤0.15 | ≤1 | ≤0.75 | ≤0.015 | ≤0.02 | ≥93 | ≤1 | ≤0.25 | ≤1.5 | 2-3.5 |
| Tensile Strength MPa(ksi) | Yield Strength MPa(ksi) | Elongation % | |
|---|---|---|---|
| AWS requirement | 380(55) | Not specified | Not specified |
| Typical results as welded | 460(67) | 260(38) | 28 |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNi-1 MIG and TIG Filler Welding Wire and Rod in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
