Chanathip Nickel Alloys and Plates, located in Bangkok, Thailand, has built a solid reputation as a reliable manufacturer and supplier of top-notch nickel-based products for international markets. They have a knack for producing Monel K500 pipes, which are celebrated for their outstanding corrosion resistance and strength, and they proudly supply these to clients in Dubai, UAE. With a commitment to precision engineering, rigorous quality control, and on-time delivery, Chanathip makes sure that every product aligns with global standards. Their deep knowledge of nickel alloys, paired with cutting-edge manufacturing capabilities, positions them as a go-to choice for industries that need durable and dependable Monel K500 pipes.
Monel K500 is an alloy that mainly consists of about 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, and aluminum. The inclusion of aluminum and titanium allows for age-hardening, boosting strength while keeping corrosion resistance intact. Its mechanical properties boast high tensile strength ranging from 800 to 1,000 MPa, along with excellent fatigue and impact resistance, and good ductility. Monel K500 holds onto its strength in both marine and chemical environments, providing exceptional resistance to seawater, acids, and alkalis. The blend of toughness, corrosion resistance, and formability makes it perfect for demanding industrial applications where durability is a must.
| Specifications | ASTM B 163 ASME SB 163 / ASTM B 165 ASME SB 165 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Size | 15″NB TO 150″NB IN |
| Specialized in | Large Diameter Size |
| Range | 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness. |
| Type | Seamless / ERW / Welded / Fabricated |
| Form | Round, Hydraulic Etc |
| Length | Single Random, Double Random & Cut Length. |
| End | Plain End, Beveled End, Treaded |
| Monel K500 | Ni | C | Al | Mn | Si | Fe | Cu | S | Ti | Cr |
|---|---|---|---|---|---|---|---|---|---|---|
| 63.0 min | 0.25 max | 2.3 – 3.15 | 1.5 max | 0.5 max | 05 – 2 | 27.0 – 33.0 | 0.010 max | 0.35 – 0.85 | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 1,60,000 , MPa – 1100 | 20 % |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel K500 Pipes Fittings in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel K500 pipes find extensive use in marine engineering, chemical processing, and desalination plants, thanks to their remarkable corrosion resistance in seawater and acidic settings. They are perfect for pump shafts, valves, heat exchangers, and condensers that demand high strength and long-lasting reliability. These pipes are also employed in offshore oil and gas facilities, aerospace components, and chemical transport systems where performance under extreme conditions is crucial. Industries that require wear and corrosion resistance, along with the ability to handle high pressures and temperatures, rely on Monel K500 pipes for both operational efficiency and safety.
