Chanathip Nickel Alloys is a trusted manufacturer and supplier of Tantalum R05255 Sheets and Plates in Bangkok, Thailand. Known for their excellent corrosion resistance, high melting point, and durability, these products are designed for industries facing extreme conditions. Tantalum R05255 sheets and plates are commonly used in chemical processing, aerospace, electronics, and medical fields because they are reliable and perform well. At Chanathip Nickel Alloys, we commit to delivering products that comply with international quality standards, ensuring long service life and reliability. With timely delivery and competitive pricing, we are the preferred supplier for Tantalum R05255 solutions.
Tantalum R05255 sheets and plates are made from high-purity tantalum with excellent resistance to strong acids, including hydrochloric and sulfuric acids. They have an extremely high melting point of around 2996°C, good thermal and electrical conductivity, and remarkable ductility, making them easier to fabricate. Their strength and stability in high-temperature environments ensure reliability in harsh conditions. Additionally, Tantalum R05255 is biocompatible, allowing for safe use in medical implants and devices. These combined properties guarantee strong performance and versatility across challenging industrial settings
| Standard Specifications | ASTM B708, ASME SB708 / ASTM F 560 |
| Thickness | 0.5 mm – 30 mm |
| Width | 10mm – 2500mm |
| Length | As Your Required |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Types | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Purity | ≥99.9% or 99.95% |
| Grade | R05200, R05400, R05255, R05252, R05240 |
| C | O | N | H | Fe | Mo | Nb | Ni | Si | Ti | W | Ta |
| 0.010 | 0.015 | 0.010 | 0.0015 | 0.010 | 0.020 | 0.100 | 0.010 | 0.005 | 0.010 | 9.0 – 11.0 | Remainder |
| Dimension | Ultimate Tensile Strength, min, psi (MPa) | Yield Strength, min, psi (MPa) (2 % Offset) | Elongation, min, % |
| < 0.125″ (3.175mm) | 70000 (482) | 60000 (414) | 15 |
| ≥0.125″ (3.175mm) | 70000 (482) | 55000 (379) | 20 |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Tantalum R05255 Sheets and Plates in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Tantalum R05255 Sheets and Plates are essential in industries that need materials with strength, stability, and corrosion resistance. In chemical processing, they are used in heat exchangers, reactors, and tanks faced with aggressive acids. The aerospace industry employs them in high-temperature applications and critical parts where safety is vital. In the medical sector, their biocompatibility makes them perfect for implants, surgical instruments, and devices. Additionally, they are vital in the electronics sector for capacitors and high-performance components because of their conductive traits and long-term reliability. Their versatility makes them a top choice for advanced engineering projects.
