Chanathip Nickel Alloys and Plates, located in Bangkok, Thailand, stands out as a top-notch manufacturer and supplier, renowned for providing high-quality nickel alloys and industrial products to customers around the globe. With a solid foothold in the Middle East, the company has established itself as a reliable Inconel 600 Forged Fittings Manufacturer in Dubai, UAE. These fittings are crafted using cutting-edge technology, which guarantees outstanding strength, durability, and impressive resistance to oxidation and corrosion. Chanathip Nickel Alloys has built a strong reputation for catering to a variety of industrial needs by offering precision-engineered solutions designed for demanding applications in the oil, gas, chemical, and power generation sectors.
Inconel 600 Forged Fittings are primarily made up of nickel (72%), chromium (14–17%), and iron (6–10%), along with small amounts of copper, manganese, and silicon. This distinctive blend gives them exceptional resistance to heat, oxidation, and corrosion, even in the harshest environments. Mechanically, they boast high tensile strength, excellent creep resistance, and good yield strength, making them perfect for heavy-duty applications. These fittings also retain superior toughness and thermal stability, ensuring reliable performance under high pressure and elevated temperatures without sacrificing structural integrity.
| Standards | ASTM, ASME |
| Designation | B564, SB564 |
| Dimension Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Grade | Inconel 600 Forged Fittings. |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Types of Forged Fittings | Elbow, Tee, Union, Cross, Swage Nipples, Coupling, CAP, Plug, Bush. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Forged Fittings in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 Forged Fittings find their place in industries that require exceptional strength and resistance to extreme conditions. They are crucial in chemical processing plants, where the ability to withstand corrosive media is essential, and in the oil and gas sectors for managing high-pressure and high-temperature situations. Power generation facilities rely on them for heat exchangers, boilers, and superheaters due to their remarkable thermal stability. Moreover, they are utilized in aerospace, marine, and food processing industries, where durability and reliability are of utmost importance. Their versatility makes them an essential component across various industrial sectors.
