Chanathip Nickel Alloys, a trusted manufacturer and supplier based in Bangkok, Thailand, specializes in delivering top-quality alloy products for various industries. Renowned for precision engineering and superior craftsmanship, we offer an extensive range of nickel alloy products, including the Inconel 625 Forged Fittings. Known for its exceptional resistance to corrosion, oxidation, and high-temperature environments, our Inconel 625 Forged Fittings are ideal for critical applications in the oil, gas, chemical, and marine industries. Choose us for reliability and excellence.
Inconel 625 Forged Fittings consist primarily of nickel (58%) and chromium (20-23%), with additions of molybdenum (8-10%), niobium (3-4%), and iron. These fittings exhibit excellent resistance to corrosion, oxidation, and pitting, even in harsh environments. They are known for their high strength, durability, fatigue resistance, and weldability. Inconel 625 forged fittings are ideal for aerospace, marine, and chemical processing industries due to their exceptional performance in high-temperature and high-stress conditions, making them versatile and reliable in demanding applications.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Forged Fittings in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Forged Fittings are widely used in applications requiring high strength, corrosion resistance and durability. They excel in harsh environments, making them ideal for applications in the chemical industry, aerospace, marine and power generation. These inserts are particularly useful in pipeline systems exposed to extreme temperatures and corrosive elements, providing reliable long-term service Their versatility also makes it suitable for oil and gas extraction, where resistance to high pressure and seawater corrosion is required.
