Chanathip Nickel Alloys and Plates, a well-respected manufacturer and supplier based in Bangkok, Thailand, specializes in top-notch A286 Sheets and Plates. These products are celebrated for their impressive strength, resistance to corrosion, and outstanding performance even at high temperatures. You’ll find these sheets and plates in a variety of industries, including aerospace, automotive, power generation, marine, and chemical processing, where durability and reliability are absolutely crucial. Thanks to their ability to resist oxidation, creep, and significant mechanical stress, A286 Sheets and Plates promise a long service life in demanding environments. Chanathip Nickel Alloys and Plates is committed to meeting global standards, ensuring timely delivery, and providing cost-effective solutions for clients around the world.
The A286 Sheets and Plates are primarily made from iron, nickel, and chromium, with added elements like titanium, molybdenum, and vanadium that boost their strength and oxidation resistance. They showcase high tensile and yield strength, excellent creep resistance, and solid toughness at both cryogenic and elevated temperatures. These characteristics make them ideal for challenging applications that require exceptional mechanical stability and long-lasting durability under high stress and temperature changes.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of A286 Sheets and Plates in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These A286 Sheets and Plates are widely utilized in industries that need materials capable of maintaining structural integrity in extreme conditions. In the aerospace sector, they’re used in components for jet engines, turbine disks, and exhaust systems. The automotive industry incorporates them into high-performance engines and turbochargers. Power generation sectors depend on them for gas turbines, boilers, and nuclear reactors. Chemical processing facilities use them in equipment that deals with aggressive chemicals and corrosive environments. Their unique combination of strength, heat resistance, and corrosion protection makes A286 Sheets and Plates a go-to choice for critical engineering and industrial applications.
