Home > Zirconium Sheet and Plate
Chanathip Nickel Alloys is a leading manufacturer and supplier of zirconium sheets and plates in Bangkok, Thailand. Our products are designed to provide strong performance in sectors like petrochemical, oil and gas, chemical processing, nuclear, and aerospace. Known for their great corrosion resistance, durability, and heat stability, zirconium sheets and plates are essential in critical applications. At Chanathip Nickel Alloys, we combine modern technology, strict quality control, and dedicated service to supply materials that meet international standards. With reliable products, reasonable pricing, and timely delivery, we are the trusted choice for high-quality zirconium sheet and plate solutions.
Zirconium sheets and plates generally contain over 99.2% zirconium with up to 4.5% hafnium, which naturally occurs with zirconium. We strictly regulate trace impurities like oxygen, nitrogen, carbon, and iron to improve material features. Mechanically, zirconium has tensile strength between 330 and 580 MPa, yield strength of 200 to 400 MPa, and elongation of 14 to 40%, depending on processing and grade. The material is very ductile, heat resistant, and has a low neutron absorption cross-section, which makes it great for nuclear applications. With excellent corrosion resistance, these features ensure versatility and reliability in tough conditions.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Products | Chemical Composition(wt%≤) | ||||||||
| Cd | Co | Cu | Hf | Mg | Mn | Mo | Si | Ti | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60802 (Zr-2) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60804 (Zr-4) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60901 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60904 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.005 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| Products | Chemical Composition (wt%≤) | ||||||||
| U | V | W | C | N | H | O | |||
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60802 (Zr-2) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60804 (Zr-4) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60901 (Zr-2.5Nb) | 0.0035 | – | 0.010 | 0.027 | 0.0080 | 0.0025 | 0.09-0.15 | ||
| R60904 (Zr-2.5Nb) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.01-0.14 | ||
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Zirconium Sheets and Plates in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Zirconium sheets and plates are highly valued for their unique mix of corrosion resistance, heat tolerance, and biocompatibility. In chemical processing, they are used in reactors, piping, and heat exchangers to manage aggressive substances. In the nuclear industry, zirconium’s low neutron absorption makes it crucial for fuel cladding and reactor parts. Aerospace manufacturers use zirconium plates for high-temperature structures and special alloys. The medical field utilizes zirconium for implants, dental applications, and surgical devices because of its great biocompatibility. Additionally, zirconium is used in electronics and industrial tools where durability and long-lasting performance are essential.
