Chanathip Nickel Alloys and Plates, located in Bangkok, Thailand, has built a solid reputation as a reliable manufacturer and supplier of top-notch Super Duplex Manifold Valves. These valves are expertly crafted for optimal flow control and distribution in critical piping and instrumentation systems. Renowned for their remarkable strength, durability, and ability to withstand harsh environments, they deliver dependable performance even in high-pressure and corrosive situations. Chanathip takes pride in producing these valves with precision, adhering to international standards, making them a fantastic choice for industries like oil & gas, chemical, power generation, and marine applications where safety and efficiency are paramount.
Super Duplex Manifold Valves are made up of about 24–26% chromium, 6–8% nickel, 3–5% molybdenum, and nitrogen, which grants them exceptional corrosion resistance and mechanical strength. Their unique duplex microstructure, featuring both ferrite and austenite, offers a superb blend of toughness and hardness. With a tensile strength of around 800 MPa and a yield strength close to 550 MPa, they also boast high fatigue resistance. Moreover, these valves excel in resisting pitting, crevice corrosion, and stress corrosion cracking, along with providing outstanding impact strength and thermal stability, making them perfect for extreme operational conditions.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
Super Duplex Manifold Valves find extensive use in industries that demand robust, precise, and reliable flow regulation. In the oil & gas sector, they are utilized in offshore platforms, subsea operations, and high-pressure pipeline systems. The chemical and petrochemical industries rely on them for process instrumentation, reactors, and control systems. Additionally, they are employed in desalination plants, marine applications, and power generation facilities due to their remarkable resistance to chloride-induced corrosion. These valves guarantee safe, efficient, and long-lasting performance, making them indispensable for challenging industrial applications across various sectors.
Contact us to get a quick quote for your requirement.
Super Duplex manifold valves are used in industries requiring high strength and superior corrosion resistance. They are commonly found in offshore oil and gas platforms, where they withstand harsh marine environments. These valves are also utilized in chemical processing plants, particularly for handling aggressive fluids and gases. Additionally, they are employed in desalination plants and power generation facilities, where their resistance to stress corrosion cracking and high pressure is crucial for reliable operation and safety.
