Chanathip Nickel Alloys and Plates, based in Bangkok, Thailand, is a well-respected manufacturer and supplier of top-notch Super Duplex Needle Valves. These valves are expertly crafted to ensure precise flow control in highly corrosive and high-pressure settings, guaranteeing durability and a long lifespan. Renowned for their outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking, the Super Duplex Needle Valves from Chanathip are built to perform reliably, even under the toughest conditions. With a strong commitment to global quality standards, the company provides valves that are trusted across various industries, including oil & gas, chemical, marine, and power generation.
The Super Duplex Needle Valves are made from a special alloy that includes 24–26% chromium, 6–8% nickel, 3–5% molybdenum, and nitrogen, all of which enhance their corrosion resistance and mechanical strength. Their unique duplex microstructure, which combines both austenite and ferrite, offers an exceptional balance of toughness and strength. On the mechanical side, they boast a tensile strength of around 800 MPa, a yield strength of about 550 MPa, and impressive fatigue resistance. Additionally, they exhibit excellent hardness, superior thermal stability, and remarkable impact strength, making them ideal for extreme operational demands.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Chanathip Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Needle Valve in Bangkok, Thailand, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Thailand, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Needle Valves find extensive use in industries where precise control of fluid and gas flow is essential. In the oil & gas sector, they are commonly found on offshore platforms, in subsea systems, and within high-pressure pipelines. The chemical and petrochemical industries utilize them in process plants, reactors, and instrumentation systems where safety and accuracy are paramount. They are also widely used in desalination plants, marine engineering, and power generation facilities. Their ability to endure chloride-rich environments ensures they deliver long-lasting performance, making them a go-to choice in industries that require both efficiency and reliability.
